| Usable Length (LU) | 4.57″ | Shank Length (LS) | 1.89″ |
| Length Group | 8D | Coolant Supply Property (CSP) | Coolant Thru |
| Application | | Drill Mill | Drilling | | Cutting Item Count (CICT) | 1 |
| Connection Diameter Machine Side (DCONMS) | 5/8″ | Measurement Type | Inch |
| Insert Seat Size Code (SSC) | 14.5 | Series/List # | STAW |
| Cutting Diameter Minimum (DCN) | 0.5709″ | Angle | 140 Degrees |
| Cutting Diameter Maximum (DCX) | 0.5866″ | Body Material | Steel |
| Functional Length (LF) | 6.929″ |
Product Features
| Family Description | Coolant Through Holds +.002/-.000 on Hole Diameter | Country of Origin | S.Korea |
Shipping Info
LocalField10
0
Package Weight
0.44
