TSC3 TT8020
| Cutting Width (CW) | 0.118″ | Insert Size | 3 |
| Corner Radius (RE) | 0.008″ | Height | 0.185″ |
| Insert Thickness (S) | 0.094″ | Number of Cutting Edges | 1 |
| Insert Length (INSL) | 0.79″ | Angle | 12 Degrees |
| Cutting Edge Material | Carbide | Measurement Type | Inch |
| Coating | TiCN | Clearance Angle Major (AN) | 7 Degrees |
| Grade | TT8020 | Body Material | Carbide |
| Cutting Direction (HAND) | Neutral | Insert Seat Size Code (SSC) | 3 |
| Application | | Ext. Grooving | Parting | |
Product Features
| Country of Origin | S.Korea |
