| Cutting Diameter (DC) | 0.031″ | Grade | IM106 AlTiN |
| Connection Diameter Machine Side (DCONMS) | 1/8″ | Tool Type | Single End |
| Depth of Cut Maximum (APMX) | 0.0938″ | Length Group | Standard |
| Overall Length (OAL) | 1-1/2″ | End Shape | Ball Nose |
| Cutting Edge Material | Carbide | Body Material | Carbide |
| Coating | AlTiN | Decimal Equivalent | 0.031″ |
| Flute Count (NOF) | 2 | Measurement Type | Inch |
| Flute Helix Angle (FHA) | 30 Degrees | Series/List # | E12-BN |
| Shank Type | Round |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
0.05
