TLANL12-16
Screw-on clamp toolholder with tangential insert for roughing operation with 93deg approach angle
| Shank Height (H) | 3/4″ | Master Insert Identification (MIID) | LNMX160608L |
| Shank Width (B) | 3/4″ | Application | | For Heavy Turning | |
| Overall Length (OAL) | 5″ | Rake Angle Axial (GAMP) | -6 Degrees |
| Functional Length (LF) | 5″ | Rake Angle Radial (GAMF) | -6 Degrees |
| Head Length (LH) | 1″ | Body Material | Steel |
| Functional Width (WF) | 1″ | Tool Type | Square Shank Turning Tools |
| Cutting Direction (HAND) | Left Hand | Measurement Type | Inch |
Product Features
| Family Description | Screw-on clamp toolholder with tangential insert for roughing operation with 93deg approach angle | Country of Origin | JAPAN |
Shipping Info
Package Weight
0.000
