NPMT 080404R-HF-I IC908
Internal and central inserts for Drilling Heads ISD-EF-FB / IDD-EF-FB
| Cutting Edge Length (L) | 0.394″ | Application | | Deep Drilling | |
| Insert Thickness (S) | 0.157″ | Applicable Material | | Steel | Stainless Steel | Cast Iron | Hard Materials | Super-Alloys / Titanium | |
| Inscribed Circle Diameter (IC) | 0.315″ | Cutting Edge Material | Carbide |
| Corner Radius (RE) | 0.0157″ | Tool Type | Gun Drill Inserts |
| Shape | Square | Measurement Type | Inch |
| Coating | TiAlN | Cutting Direction (HAND) | Right Hand |
| Grade | IC908 | Body Material | Carbide |
Product Features
| Family Description | Internal and central inserts for Drilling Heads ISD-EF-FB / IDD-EF-FB | Country of Origin | Japan |
