| Thread Diameter Size (TDZ) | 5/8″ | Thread Tolerance Class (TCTR) | H3 |
| Threads per Inch (TPI) | 11 | Chamfer | 4P-4.5P |
| Thread Standard | NC | Coating | Black Oxide |
| Overall Length (OAL) | 6″ | End Shape | Chamfer |
| Usable Length (LU) | 2.598″ | Style | Plug |
| Connection Diameter Machine Side (DCONMS) | 0.632″ | Measurement Type | Inch |
| Flute Count (NOF) | 4 | Flute Type | Straight |
| Applicable Material | | Steel | Cast Iron | | Series/List # | 916 |
| Cutting Edge Material | HSS | Thread Size | 5/8″ - 11 |
Product Features
| Remarks | •Steam Oxide Plug Pulley Taps | Country of Origin | Mexico |
Shipping Info
Package Length
6.05000
Package Width
1.00000
Package Height
.90000
Package Weight
0.5
